APPLICATIONS
These highly flexible connection cables are particularly suitable for areas of application with high demands on resistance to oil, acid and chemicals. They are resistant to most oils, fuels, alkalis, aliphatic and aromatic hydrocarbons as well as to most acids and alcohols. They are suitable for robust operation, are resistant to water and weather influences and retain their flexibility even at low temperatures.
[table striped=”true” bordered=”true” head_style=”true”][table_head][table_row][table_heading_cell]CABLE CONSTRUCTION[/table_heading_cell][table_heading_cell][/table_heading_cell][/table_row][/table_head][table_body][table_row][table_cell]Conductor[/table_cell][table_cell]Stranded Copper Wire Class 5[/table_cell][/table_row][table_row][table_cell]Insulation[/table_cell][table_cell]TI2 PVC[/table_cell][/table_row][table_row][table_cell]Insulation Colours[/table_cell][table_cell]Grey, Brown, Black[/table_cell][/table_row][table_row][table_cell]Stranding[/table_cell][table_cell]Cores Twisted In Layers[/table_cell][/table_row][table_row][table_cell]Outer Sheath[/table_cell][table_cell]TPK RAL2003 Orange[/table_cell][/table_row][table_row][table_cell]Product Types[/table_cell][table_cell]LiY30Y[/table_cell][/table_row][table_row][table_cell]Packing[/table_cell][table_cell]500 – 1000 mt[/table_cell][/table_row][/table_body][/table]
[table striped=”true” bordered=”true” head_style=”true”][table_head][table_row][table_heading_cell]ELECTRICAL PARAMETERS[/table_heading_cell][table_heading_cell][/table_heading_cell][/table_row][/table_head][table_body][table_row][table_cell]Working Temperature[/table_cell][table_cell]- 10 ºC + 80 ºC[/table_cell][/table_row][table_row][table_cell]Bending Radius ( min.)[/table_cell][table_cell]10 x D[/table_cell][/table_row][table_row][table_cell]Working Voltage[/table_cell][table_cell]300/500 V[/table_cell][/table_row][table_row][table_cell]Insulation Resistance[/table_cell][table_cell]>200 m Ω x km[/table_cell][/table_row][table_row][table_cell]Conductor Resistance[/table_cell][table_cell]0,22 mm²:96 Ω/km – 0,50 mm²:39 Ω/km – 0,75 mm²:26 Ω/km – 1,00 mm²:19,50 Ω/km – 1,50 mm²:13,30 Ω/km – 2,50 mm²:7,98 Ω/km[/table_cell][/table_row][table_row][table_cell]Test Voltage[/table_cell][table_cell]0,22 mm² : 1200 V – 0,50 mm² : 1200 V – 0,75 mm² : 1200 V – 1,00 mm² : 1200 V – 1,50 mm² : 2500 V – 2,50 mm² : 2500 V[/table_cell][/table_row][/table_body][/table]
